Dump truck · from 1975
KamAZ-5510
Power
180hp
Top speed
80km/h
Displacement
10.8l
Weight
8270kg
Description
Engine — YaMZ-7401, diesel, V-type, four-stroke, eight-cylinder, overhead-valve, 10.8 l displacement. Gearbox: five-speed. Clutch: twin-plate, dry, hydraulically operated. Final drive: double: a pair of bevel gears and a pair of spur gears. Steering gear: two-stage: recirculating-ball screw and nut with rack and sector; power-assisted. Kerb weight — 8270 kg.
Specifications are taken from the archived autoussr.ru reference book.
Data sheet
- Production period
- from 1975
- Dimensions (L × W × H)
- 6560 × 2500 × 2680 mm
- Seats
- 3
- Payload
- 7000 kg
- Kerb weight
- 8270 kg
- Gross weight
- 15495 kg
- Wheelbase
- 3500 mm
- Ground clearance
- 285 mm
- Top speed
- 80 km/h
- Fuel consumption
- 20.5 l/100 km
- Engine
- YaMZ-7401, diesel, V-type, four-stroke, eight-cylinder, overhead-valve
- Displacement
- 10.8 l
- Compression ratio
- 17
- Maximum power
- 180 hp
- Clutch
- twin-plate, dry, hydraulically operated
- Gearbox
- five-speed
- Final drive
- double: a pair of bevel gears and a pair of spur gears
- Steering gear
- two-stage: recirculating-ball screw and nut with rack and sector; power-assisted
- Tyre size
- 260-508
Source: the autoussr.ru reference archive
